MULTITANK fronttartály
Front tank for nutrient application
The NorAn Multitank family is a multifunctional, combined application system that applies soil bacteria and fertilizers in one pass with the soil work.
This makes it a very economical and efficient solution. It can be assembled in different configurations to meet different needs, taking into account the farmer’s requirements, the specific soil work and the specific characteristics of the machinery.
660-1100L
2.5-18.0m
50-190 LE
2418-4748 kg
Key features
Appropriate pressure (something else might be more appropriate)
The NorAn Multitank can be ordered with different pumps according to the intended application.
In the case of bacteria or lower doses of liquid fertiliser, you can choose between 12V electric pumps with a maximum capacity of 20.8 and 26.5 l/min.
They allow for achieving a maximum of 150-200 l/ha under the following parameters (pressure: 2bar; speed: 10 km/h; working width: 6 m). If you do not want to compromise on the upper limit of the quantity applied, you should always choose the hydraulically driven 115 l/min Annovi Reverber diaphragm pump.
Pinpoint control system
Depending on the type of pump, the control always delivers the liquid in proportion to the speed of travel, ensuring that an even litre/ha dose is applied to all parts of the field.
The system is based on a large 10″ tablet, which allows you to keep track of all important data and easily make the necessary adjustments.
The speed is determined by GPS.
In end-of-field turns, when the implement is lifted, the implement switch immediately stops the spreading and automatically starts it once the manoeuvre is completed, making operation very convenient.
ISOBUS control is also available as an option for tanks with hydraulic motor pump, allowing you to control your Multitank front tank from your tractor’s own monitor.
Unlimited possibilities
The NorAn Multitank can be assembled in different configurations according to the farmer’s needs, the current soil work or the specific characteristics of the machines.
The tool can be mounted on the three-point front hydraulics of the power tool or, if not available, on the nose weight bracket with a custom adapter attachment, or on the implement (seeder, cultivator, disc, etc.) with machine-specific settings and component configuration.
The different configurations are easy to set up, as the main components of the NorAn Multitank set are the same for each workflow, and the number or sizing of additional components (spray frame, nozzles, lines, etc.) can be adapted to the task at hand.
Applications
• application in one pass with sowing with the injection device mounted on the seed drill
• application when making the seedbed using an application implement mounted on soil tillage implement or tank-mounted spreading frame
• application during row gap cultivation
• stubble treatment using application implement mounted on any device
• when ploughing, using an application implement mounted on the plough
or disc
Interested in this machine? Have a question? Call now! +36 30 601 31 61
Technical data
| NorAn Multitank | HF 1100 | HF 660 | EF 1100 | EF 660 | ER 1100 | ER 660 |
|---|---|---|---|---|---|---|
| Working width (m) | 3-12 | 3-12 | 3-12 | 3-12 | 3-12 | 3-12 |
| Weight of the core machine (kg) | 330 | 300 | 290 | 260 | 290 | 260 |
| Tank capacity (L) | 1100 | 660 | 1100 | 660 | 1100 | 660 |
| Working speed (km/h) | 6-16 | 6-16 | 6-12 | 6-12 | 6-12 | 6-12 |
| Application range (L) | 80-380 | 80-380 | 80-180 | 80-180 | 80-180 | 80-180 |
| Pump capacity (litres/min) | 115 | 115 | 115 | 115 | 115 | 115 |
| Pump type: | Hydraulic | Hydraulic | Elektromos (12V) | Elektromos (12V) | Elektromos (12V) | Elektromos (12V) |
| Type of suspension/fixing: | 3-point Cat. II / front weight in place | 3-point Cat. II / front weight in place | 3-point Cat. II / front weight in place | 3-point Cat. II / front weight in place | Number of hydraulic circuits | Number of hydraulic circuits |
| Number of hydraulic circuits | 1 DA | 1 DA | - | - | - | - |
| Traction power requirements (from HP) | 80-110 | 80-110 | 80-110 | 60-90 | 80-110 | 60-90 |
DA = double action (min. 180 bar)
HF = Hydraulic pump tank front suspension
EF = Electric pumped tank front suspension
ER = Electric tank mounted on a machine
Noran Multitank
Options
front spreading frame (3-4-5-6 m)
suction hose set (with 8m D50 hose)
ISOBUS control
Tank mounting bracket (for disc, row cultivator, seedbed maker)
Gallery
Contact us
Do you need help choosing or would you be interested in seeing one of the machines? Contact us!
Phone number:
+36 30 601 31 61
The high accuracy speed signal is provided by a built-in GPS antenna.
All NorAn Multitanks come standard with speed proportional application control.
This means that the application rate in l/ha is pre-recorded in the control monitor and the system varies the pressure based on the measured working speed, ensuring that the amount of l/ha applied remains the same over the whole area, regardless of the speed.
